IC Packaging
Discover our expertise in IC Packaging.
Protronics Packaging services include microelectronics and optics assembly and packaging. Our prototyping Foundry uses methods ranging from 2D die attach and wire bond assembly to multiple 2.5D and 3D integration schemes. Our wirebonding capabilities include manual and automated wedge and ball wirebonders and pull testers. Our 2.5D packaging platforms include large-format interposers for integration. Our 3D integration technologies range from die stacking and flip-chip bump bonding to advanced integration technologies utilizing through-silicon vias or wafer bonding with high-density, low-capacitance interconnects. Performance needs, form factor, security, and cost all play a role in deciding which approach to use.
- Package design and selection (ceramic and plastic substrates)
- Thermal management
- Materials selection and evaluation
- Packaging and assembly process development
- Full custom microsystems and integration
- Manual and automated, precision die placement
- Conductive and nonconductive organic (epoxy) die attach materials
- Eutectic die attach
- Programmed Die Encapsulation
- Hermetic ceramic packaging
- Solder lid seal
- Parallel seam sealing
- Glob top
- Dam and fill
- Manual and automated wire bonding
- Aluminum and gold wire
- Wedge and ball bonding
- Fine pitch (down to 50 µm)
- High wire count
- wire bonding to ceramic, organic and metal packages
- Eutectic and high Pb solders
- Au stud bumping (wafer or die)
- Plastic and ceramic substrates
- Precision underfill dispensing
- Multi-chip modules
- Thermo-compression bonding
- Die-to-die, wafer-to-wafer, and die-to-wafer
- MEMs packaging and assembly
- Packaging and assembly process development
- RF assembly
- Mechanical Assembly
- Optoelectronic assembly
- Flex circuit assembly
- Surface mount
- Rework and repackaging
- 3-D X-Ray Tomography
- Scanning Acoustic Microscopy
- White Light Interferometry
- Gross and Fine Leak Testing of Hermetic Packages
- Mil-Std Inspection
